FS1-X v1.1 www.aja.com 110
SNMP Configuration Parameters
4.0 SNMP Enable
The SNMP Enable parameter Enables or Disables SNMP messaging between the FS1-X
and an external client.
When Enabled, menus described below are available for configuration.
4.1 SNMP Trap
Destination 1
This parameter determines the SNMP Trap Destination IP address where trap messages
issued by the FS1-X will be sent.
4.2 SNMP Trap
Port 1
This parameter determines the SNMP Trap Port 1 used for sending destination #1 trap
messages. UDP Port 162 is the default used for SNMP trap messages. However, if this port
is being used by another protocol or service, you can change the setting by modifying
this parameter.
NOTE: The SNMP Trap Port number does not blink when changed (as does the Trap Destination IP
address); if you change the port number and exit the parameter, the port changes
immediately to the new value.
4.3 SNMP Trap
Destination 2
This parameter determines the secondary SNMP Trap Destination IP address where trap
messages issued by the FS1-X will be sent (if desired). This parameter is similar to
"4.1
SNMP Trap Destination 1" above.The default is 192.168.0.3.
4.4 SNMP Trap
Port 2
This parameter determines the SNMP Trap Port used for sending destination #2 trap
messages, similar to
"4.2 SNMP Trap Port 1" above. Default is 162.
Disabled (default)
Enable 1
Enable Both
When set to Disabled, the FS1-X will not issue SNMP trap messages.
When set to Enable 1, the FS1-X issues SNMP trap messages to Trap
Destination 1 (parameter 4.1) and as defined in the MIB.
When set to Enable Both, the FS1-X issues SNMP trap messages to
Trap Destination 1 and 2 (parameters 4.1 and 4.3) and as defined in
the MIB.
IP Address Set the desired IP address where traps will be sent (usually a client
on your LAN). Default: 192.168.0.3
Variable Select a UDP port for sending FS1-X trap messages. Default: 162
