FS1-X v1.1 www.aja.com 115
Video Format Alarms When incompatible I/O formats are detected, an alarm can be triggered with these
results:
• Lights the relevant alarm LED on the front panel (FMT ERROR, 1 or 2).
• Displays an alarm in the browser user interface.
• Influences selection of the first-displayed status screen.
• Generates an SNMP trap (if configured).
• Triggers a GPI Output (if configured).
Video A/D, D/A Converters
• 12 bits
• 2x oversampled (HD)
• 4x oversampled (SD)
Audio
Inputs and Outputs The FS1-X can accept and route any audio inputs to any audio output.
• 8-channel balanced analog I/O, DB-25F 25-pin connector (Tascam pinout)
• 16-channel AES/EBU I/O (BNC), DB-25F 25-pin connector
• 16-channel SDI/HD-SDI embedded BNC (2)
• 16-channel SDI/HD-SDI embedded Fiber (2)
• 64-channels MADI digital audio. BNC
• 64-channels MADI digital audio. Fiber
Analog Audio Levels Analog audio input and output levels, as referenced to full scale digital, can be set to:
• +12dBu (consumer), +15dBu, +18dBu, +24dBu (professional)
Audio Adjustments Individual audio channels (or channel pairs) can adjusted for:
• Level: +/- 18 db
• Phase: Normal or Reverse
1080i5994
625i50
720p50
1080i50
1080p50
2K1080P50
625i50
720p50
1080i50
1080p2398
1080p24
1080p25
1080p2997
1080PsF25
1080PsF2997
1080p5994
1080PsF2398
1080PsF24
525i5994
720p5994
Table 7. Supported Conversions, FRC Enabled (continued)
