• Delay: -128 to +12288 samples (-2.7 ms to +256 ms)

Interfaces

LAN

• 10/100/1000 automatic configuration

• Automatic cable crossover (auto MDI-X)

• Embedded web server

• SNMP

GPI

• DB-15F: single connector provides four inputs and four outputs. See Appendix B for a

connector pinout and GPI specifications.

Physical

Dimensions

• Width: 17.5 inches (44.45cm); 19 inches (48.26 cm) including rack ears

• Depth: 16 inches (40.65 cm), including knobs and connectors that extend beyond the

frame

• Height: 1RU, 1.75 inches (4.44cm)

Weight

• 7.85 pounds, 3.56 kilograms

Temperature

• Operating temperature range: 0–40 degrees C

• Cooled via two internal fans and side vents.

Power

• Voltage: 100-240 VAC

• Power Consumption: 55 Watts, 60 Watts with FRC option (70 Watts maximum)

• Two independent power supplies, fully redundant, diode isolated.
