2.1 IP Config
This parameter determines the type of TCP/IP network configuration used by the FS1-X.
Consult your network administrator about how to set this value.
2.2 IP Address
This parameter determines the static IP address used by the FS1-X for TCP/IP networking.
Consult your network administrator about how to set this value.
Octet Value Entry
Procedure
Set the octets (numbers between periods) values as follows:
1. Push ADJUST momentarily to enter edit mode.
2. Turn SELECT to select the octet you want to edit, indicated by blinking.
3. Turn ADJUST to enter the new value.
• If you need to revert to the previous setting (undo changes), push SELECT.
4. Push ADJUST momentarily to save and activate the new setting.
• If you want to revert to the default value, hold down ADJUST for 4 seconds.
2.3 Subnet Mask
This parameter determines the subnet mask used by the FS1-X for TCP/IP networking.
Consult your network administrator about how to set this value.
2.4 Default Gateway
This parameter determines the gateway or router used on your LAN for TCP/IP
networking. Consult your network administrator about how to set this value.
Without a properly configured default gateway (whether you have a router/gateway or
not), the FS1-X will be unable to see other FS1-Xs on the network, although you may still
be able to control this FS1-X via a web browser. Also, without a proper gateway defined,
the discovery feature on the Network web page will fail to list other FS1-Xs on the
network.
DHCP (default)
Static Addr
Select automatic IP address assignment from the LAN DHCP server. If
the FS1-X cannot find a DHCP server, it fails over to the static IP
address.
Assign a static IP address manually (using the following parameter
menus).
The factory default static IP address: 192.168.0.2
IP Address variable If IP Config is set to DHCP dynamic addressing (default), the IP Address is
set automatically by the network's DHCP server.
If IP Config is set to Static Addr, manually enter an IP address.
If IP Config is set to DHCP and there is a DHCP failure, the IP address is set
to the static IP address. The factory default static IP address is
192.168.0.2.
Subnet Mask variable Enter a subnet mask compatible with your LAN. This is only needed
for Static IP configurations.
If 2.1 is set to DHCP, the Subnet Mask is set by the DHCP server and
cannot be changed by the user.
If 2.1 is set to Default Addr, the default Subnet Mask is 255.255.255.0
Gateway Address variable Enter the address of the gateway or router used to connect the
FS1-X to the network. Default: 192.168.0.1
