FS1-X v1.1 www.aja.com 47
Menu Parameter
Interactions
Several FS1-X menus interact with one another, such that changing a parameter value in
one menu may change the settings of another menu, change what settings are available
in other menus, or cause settings that exist in other menus to be ignored.
Figure 11 shows
some of these relationships.
Figure 11. FS1-X Menu Parameter Interactions
STATUS Menu Group
The Status Menu Group contains a series of Status display pages that you can scroll using
the SELECT knob. The various Status pages are actually just displays, not menus, since
they don’t include menu numbers or editable values. The ADJUST knob doesn’t affect the
Status display pages.
When you press the STATUS button, the display shows the first menu unless there is an
active alarm. If an alarm is active, the relevant alarm status page is displayed first. If more
than one alarm is active, the highest priority alarm page is displayed first.
Timing & Delay
Region of Interest
Background Fill
Custom Size/Pos
Downconvert Mode
Proc Amp
Color Corrector
Video Input
Output Format
VIDEO PROC Menus
Analog In Format
FRC Enable
NTSC Standard
Output Frame Rate
SYSTEM Menus
Phase
Delay
Level
AUDIO PROC Menus
Audio Outputs
AUDIO OUTPUT Menus
Hidden Menus
CONFIG Menus
Hides unnecessary
sub-menus in all
other menus and
web pages.
When Auto AFD
Disabled
Disabled
When Video Input is Analog,
Analog In Format settings
are used.
Active only for 59.97/23.98
Output Frame Rate
All Outputs assigned
to Video Proc 2
VIDEO OUTPUT Menus
When Enabled
Cannot use Vid 2 for
Background Fill
Video Proc 2 Outputs Black
