FS1-X v1.1 www.aja.com 56
7 Reference Alarm
This parameter controls how the FS1-X responds when one of the Video Processors has a
format that is incompatible with the Reference video signal. When set to NORMAL, the
alarm triggers if the Reference signal is not detected or is incompatible with the
processor format. If you want the FS1-X Reference alarm to trigger only on hardware
failures, you can suppress the alarm. Changes to this setting are automatically saved.
NOTE: For proper operation the Input reference signal must be stable and properly terminated using
a 75-ohm terminator on either the unused loop connector or the last piece of downstream
equipment to which the Ref Video is connected.
8 Hidden Menus
This parameter lets you choose whether to hide or show inactive menus.
9 Screen Saver
This parameter lets you choose the menu screen saver.
10 Display Intensity
This parameter determines the brightness of the alphanumeric display and front panel
LEDs.
11 Fan Speed
This parameter determines the speed (and sound level) of the FS1-X's internal cooling
fans. To prevent system damage, this setting may be overridden temporarily, and the fan
can be set to a higher speed if the system detects very high internal temperatures.
Changes to this setting are automatically saved
12 Serial Number
This parameter displays the FS1-X’s unique serial number.
13 Software Version
This parameter displays the FS1-X’s software version number.
14 Reboot
This parameter lets you reboot the FS1-X. Press and hold in both front panel knobs
simultaneously to reboot.
During reboot, the display shows [Rebooting], goes dark momentarily, and then shows
the percentage of progress as the system reboots. Rebooting takes a couple of minutes.
Normal (default)
Suppress
Alarm triggers if the reference signal is not detected or is
incompatible with the processor format.
Alarm will not be triggered by reference errors.
Hide Inactive (default)
Show All Hides menus that are not in use.
Shows all menus, even those that are not in use.
On (AJA Logo) (default)
System Name AJA logo screen saver is displayed
Screen saver displays the system name.
Variable Dim or brighten the alphanumeric display and activity indicator
LEDs in steps from 1 (dim) to 8 (brightest). Default: 6
Variable Changes the fan speed in steps from 1 (slow) to 10 (fast).
Default is 10.
