FS1-X v1.1 www.aja.com 81
2.1 Fiber1 Video
Out
2.2 Fiber2 Video
Out
3 HDMI Video Out
4 Analog
This parameter selects the video processor output to be sent out the three Component
and the single Composite analog FS1-X outputs.
Different signals are sent depending on the assigned Video Processor configuration.
• If the video processor assigned is configured for SD output, SD component is sent to
the Component outputs, and SD composite is sent to the Composite output.
• If the video processor assigned is configured for HD output, HD is sent to the
Component outputs, and SD is sent to the Composite output.
• If the video processor assigned is configured for 3G output, HD is sent to the
Component outputs, and SD is sent to the Composite output.
5.1 SDI1 3G Config
The SDI13G Config parameter determines how 1080p50/59.94 signals are formatted for
the SDI 1 output. The first two choices select either “Level A” or “Level B” as described in
the SMPTE 425 standard. The third selection ties SDI 1 Out and SDI 2 Out together into a
single 1.5 Gb Dual-link 1080p50/59.94 output. In this case, the SDI2 Video Out and SDI2
Audio Out selections are ignored.
5.2 SDI2 3G Config
The SDI2 3G Config parameter determines how 1080p50/59.94 signals are formatted for
the SDI 2 output. The two choices select either “Level A” or “Level B” as described in the
SMPTE 425 standard. (If the SDI1 selection is Dual Link, these SDI2 settings are ignored
because the SDI 2 output is used for dual link.)
Vid 1 (default)
Vid 2 Sends the output of Video Processor 1 to the Fiber1 output.
Sends the output of Video Processor 2 to the Fiber1 output.
Vid 1
Vid 2 (default) Sends the output of Video Processor 1 to the Fiber2 output.
Sends the output of Video Processor 2 to the Fiber2 output.
Vid 1 (default)
Vid 2 Sends the output of Video Processor 1 to the HDMI output.
Sends the output of Video Processor 2 to the HDMI output.
Vid 1 (default)
Vid 2 Sends the output of Video Processor 1 to the Analog video outputs.
Sends the output of Video Processor 2 to the Analog video outputs.
3 Gb-Level A (default)
3 Gb Level-B
1.5 Gb Dual Link Formats 3G SDI Output as Level A.
Formats 3G SDI Output as Level B.
Formats SDI 1 and SDI 2 as 1.5Gb “Dual Link.”
3 Gb-Level A (default)
3 Gb-Level B Formats 3G SDI Output as Level A.
Formats 3G SDI Output as Level B.
