FS1-X v1.1 www.aja.com 50
System Status
This menu shows the FS1-X's System Name, IP address and mask, and version number.
NOTE: The IP parameters shown here on the STATUS menu group System Status menu are the actual
settings of the Ethernet interface, as read from the interface. The CONFIG menu group IP
configuration parameters show the values the FS1-X is supposed to use to configure the
interface (they are read from memory). If there is ever a discrepancy between the two, the
STATUS screen is the more correct.
REMOTE Menu Group
The REMOTE Menu Group lets you set up how you want the FS1-X to be controlled.
Control options include the front panel, a remote computer running a browser, and GPI
inputs and outputs.
NOTE: The Remote Menu Group parameters available on the front panel interact with the browser
parameters available on an attached computer, and vice versa. For example, the Remote
Control parameter can only be changed from the front panel, and when set to Local Only will
deactivate all browser remote control parameters.
1 Remote Control
This parameter determines whether the FS1-X panel responds to controls locally from
the front panel, from a network attached computer with a web browser, or both. The
selected mode is indicated by the color of the REMOTE LED.
1.1 Authentication
This parameter enables or disables an authentication login requirement. By default this
parameter is set to Disabled.
When you select Login via the front panel parameter, you must then go to the browser
interface to perform a login each time you access the FS1-X. The browser presents the
login screen first, requiring you to log in before you can access any other browser
screens. The password is initially set to the default value, but you can change it using the
Remote browser screen.
The default password is password.
Display Description
System Name
IP addr value
IP Mask value
Version value
Displays the System Name as set in Config menu 1.
Shows the IP address.
Shows the IP mask.
Shows the software version number.
Local + Remote (default)
Local Only
Remote Only
Control the FS1-X from the front panel, a remote control panel, or
a network-attached browser. The REMOTE LED lights amber.
Control the FS1-X only from the front panel (browsers cannot
change parameters). The REMOTE LED lights green.
Control the FS1-X only from a network attached browser or
remote control panel. The REMOTE LED lights red.
