FS1-X v1.1 www.aja.com 76
17.1 AFD Out These determines whether the Video Processor inserts an ADF packet into the output
video.
17.2 AFD VANC Output
Lines
This parameter determines which video output lines have AFD VANC inserted (HD output
only) on the Video Processor output.
OFF (default) The FS1-X does not insert an AFD code into the output. If the video input has a AFD
code and the FS1-X is not up/down/cross-converting it, the input AFD code will be
passed through to the output.
Auto If the FS1-X is not Upconverting or Downconverting the input video, the input AFD
code is passed through. If there is no AFD code on the input video, a “Full Frame” (8)
code is inserted. If the FS1-X is Upconverting, the appropriate AFD code will be
chosen based on the Upconvert mode.
>16:9 The FS1-X always inserts a “Box > 16:9 (center)” AFD code (4), which indicates that the
HD image has an aspect ratio greater than 16:9 as a vertically centered letterbox
within the 16:9 frame.
Full Frame The FS1-X always inserts a “Full Frame” AFD code (8), which indicates that the HD image
is full frame, with an aspect ratio that is 16:9.
Pillarbox The FS1-X always inserts a “4:3 (center)” AFD code (9), which indicates that the HD
image has a 4:3 aspect ratio as a horizontally center pillarbox image within the 16:9
frame.
Letterbox The FS1-X always inserts a “16:9 (with complete 16:9 image protected)” AFD code (10),
which indicates that the HD image is full frame, with a 16:9 aspect ratio and all image
areas are protected.
14:9 The FS1-X always inserts a “14:9 (center)” AFD code (11), which indicates that the HD
image has a 14:9 aspect ratio as a horizontally centered pillarbox within the 16:9
frame.
4:3 Alt 14:9 The FS1-X always inserts a “4:3 (with alternate 14:9 center)” AFD code (13), which
indicates that the HD image has a 4:3 aspect ratio and with an alternative 14:9
centered pillarbox image within the 16:9 frame.
16:9 Alt 14:9 The FS1-X always inserts a “16:9 (with alternative 14:9 center” AFD code (14), which
indicates that the HD image has a 16:9 aspect ratio with an alternative 14:9 center
within the 16:9 frame.
16:9 Alt 4:3 The FS1-X always inserts a “16:9 (with alternative 4:3 center)” AFD code (15), which
indicates that the HD image has a 16:9 aspect ratio with an alternative 4:3 center
within the 16:9 frame.
10 (default)
9–42 Adds AFD VANC to line 10.
Select which line other than 10 will have AFD VANC added.
