FS1-X v1.1 www.aja.com 48
I/O Status
This menu shows the current primary settings for Video Processors 1 and 2.
Vid1 Format Status
This menu shows the current primary video settings for Video Processor 1.
Vid1 Format Alarm
Status
This menu shows the Video Processor 1 alarm status. Absence of alarm shows as OK. If
selections are incompatible, the status of the affected signal shows incompat.
Vid2 Format Status
This menu shows the current primary video settings for Video Processor 2.
Vid 2 Format Alarm
Status
This menu shows the Video Processor 2 alarm status. Absence of alarm shows as OK. If
selections are incompatible, the status of the affected signal shows incompat.
Display Description
IN1 Sel Video Format
OUT1 Sel Video
IN2 Sel Video Format
OUT2 Sel Video
Video Processor 1 selected video input and detected
format.
Video Processor 1 video output format.
Video Processor 2 selected video input and detected
format.
Video Processor 2 video output format.
Display Description
IN1 Input Source Format
BKGD Backgd Source
GEN Genlock SourceFormat
OUT1 Format
Selected Video Processor 1 video input source and format.
Selected Background video source.
Selected Genlock source and format.
Selected Video Processor 1 output format.
Display Description
IN1 Input Source Status
BKGD Backgd SourceStatus
GEN Genlock SourceStatus
OUT1 Status
Selected Video Processor 1 video input source alarm status.
Selected Background video source alarm status.
Selected Genlock source alarm status.
Selected Video Processor 1 output format/alarm status.
Display Description
IN2 Input Source Format
GEN Genlock SourceFormat
OUT2 Format
Selected Video Processor 2 video input source and format.
Selected Genlock source and format.
Selected Video Processor 2 output format.
Display Description
IN2 Input Source Status
GEN Genlock SourceStatus
OUT2 Status
Video Processor 2 video input source alarm status.
Genlock source alarm status.
Video Processor 2 output format/alarm status.
