12.4 Proc Amp Sat This parameter adjusts the video color saturation from black and white to 1.5 times
chroma in steps of 0.01.
Color Corrector
(RGB)
13.0 Color Corrector
(RGB)
This parameter turns the RGB Color Corrector On and Off. When it is On, you can set
additional parameters to control RGB video Gain, Black Level, and Gamma. When set to
Off, all RGB Color Corrector settings are programmed for unity (or bypass).
Source Memory Independent RGB Color Correct parameter values are kept for each input format.
13.1 Color Red Gain This parameter adjusts the RGB Red Gain.
13.2 Color Red Black
Level
This parameter adjusts the RGB Red Black level.
13.3 Color Red Gamma This parameter adjusts the RGB Red Gamma.
13.4 -13.6 Color Green This set of parameters adjusts the Gain, Black Level, and Gamma for color Green, same as
Color Red described above.
13.7-13.9 Color Blue This set of parameters adjusts the Gain, Black Level, and Gamma for color Red Blue, same
as Color Red described above.
Custom Conversion
Settings
The custom settings determine the image size and shape for Upconvert and
Downconvert modes if you choose the Custom selection for those modes.
Custom settings are stored separately for each Conversion Mode. Values for each of the
Upconvert modes, Downconvert modes (excluding AFD), and SD Aspect Ratio modes
(excluding OFF), plus no conversion (or HD CrossConvert), are independently stored.
NOTE: If Custom Size/Pos is On and any of the following parameter are not set to unity, the front
panel UFC LED lights.
14.0 Custom Size/Pos This parameter turns custom image settings On or Off.
Variable Adjusts Proc Amp Saturation from 0 (black & white) to 1.5
(Chroma) in steps of 0.01.
Default: 1.0
Off (default)
On
Sets the RGB Color Corrector to Off.
Sets the RGB Color Corrector to On, enabling the following Color
Corrector parameters.
Variable Adjusts Red Gain from zero to 1.5 in 0.01 steps.
Default (unity): 1.0
Variable Adjusts Red Black level from -20 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
Variable Adjusts Red Gamma level from -1.0 to +1.0 in 0.01 steps.
Default (unity): 0
