• Video output selections
• SDI and Fiber 3G output configuration
AUDIO PROC Displays the Audio Processor Menu Group, used to control the adjustable audio
parameters:
• Audio level, phase, and delay settings
• Embedded audio out settings
• 5.1 and 7.1 Mix Down adjustments
AUDIO OUTPUT Displays the Audio Output Menu Group, used to control the routing of the audio sources
• Audio source selections
• Global output selection
• Output mapping controls
Control Knobs
These are the general rules of SELECT and ADJUST knob operation:
SELECT Turning the SELECT knob performs these actions:
• Turn SELECT in either direction to scroll through the menus.
• Stop on a menu to enter that menu for editing.
• Turn SELECT within a menu to scroll through multiple parameters.
• Pause on a parameter to select it for editing. For multiple fields in a parameter, use
SELECT to move through the fields (after pressing Adjust to enter field editing mode).
• Push SELECT momentarily to undo and restore the previous setting.
ADJUST Turning the ADJUST knob performs these actions:
• Turn ADJUST to change the values of a selected parameter.
• In most cases, leaving a value in place for a moment sets that value.
• To perform special actions, such as recalling a register, push the knob to confirm the
displayed value. Display line 4 indicates such special actions.
• Some parameters having multiple fields, such as IP Address require you to push the
ADJUST knob to select a field, and push again to save changes.
• Hold down the knob to reset a value to the factory default; for multiple field values, all
fields are reset to the default.
Table 1. SELECT and ADJUST Knob Operation Summary
Function Knob Action
Scroll through menus.
Scroll through parameters in a multiparameter menu.
Scroll through numerals or letters in a parameter. Turn SELECT backwards or forward.
Enter edit mode for a menu.
Enter edit mode for a parameter.
Enter edit mode for values, numerals, or letters.
Advance to the next value, numeral, or character to edit. Turn and stop SELECT on the item to edit. (For some
multiple parameter menus, push ADJUST so that the
selected parameter blinks.)
Increment/decrement a value. Turn ADJUST.
Coarse adjust a value. Hold down button and turn ADJUST.
