FS1-X v1.1 www.aja.com 82
6.1 Fiber1 3G Config
The Fiber1 3G Config parameter determines how 1080p50/59.94 signals are formatted for
the Fiber 1 output. The first two choices select either “Level A” or “Level B” as described in
the SMPTE 425 standard. The third selection ties Fiber 1 Out and Fiber 2 Out together into
a single 1.5 Gb Dual-link 1080p50/59.94 output. In this case, the Fiber2 Video Out and
Fiber2 Audio Out selections are ignored.
6.2 Fiber2 3G Config
The Fiber2 3G Config parameter determines how 1080p50/59.94 signals are formatted for
the Fiber 2 output. The two choices select either “Level A” or “Level B” as described in the
SMPTE 425 standard. (If the Fiber1 selection is Dual Link, these Fiber2 settings are ignored
because the Fiber 2 output is used for dual link.)
AUDIO PROC Menu Group
The following descriptions explain the Audio Proc Menu Groups, which allows you to
make adjustments to the audio inputs to the FS1-X audio processor.
The Audio Proc Menus are formatted as follows
1.0 SDI1 Level
This parameter selects the Audio Level Mode for all 16 SDI1 audio input channels. The
default Unity setting applies 0.0. db gain to all the input channels
When Adjust mode is selected:
• After selecting an individual channel adjustment menu, the ADJUST knob changes the
value shown by 0.5 dB (up or down) for each knob detent.
• The range of adjustment is -18.0dB to +18.0dB.
• Switching from Unity to Adjust will apply the individual level values that were set in the
Adjust mode to the input for each of the channels. Switching from Adjust to Unity will
apply unity (0.0dB) to all channels.
1.1-1.16 SDI 1 Channel
Levels
When Adjust is selected above, individual SDI 1 audio channel menus become available,
permitting +/- 18.0 dB level adjustment to each input channel.
3 Gb-A (default)
3 Gb-B
1.5 Gb Dual Link Formats 3G Fiber 1 Output as Level A.
Formats 3G Fiber 1 Output as Level B.
Formats Fiber 1 and Fiber 2 as 1.5Gb “Dual Link.”
3 Gb-Level A (default)
3 Gb-Level B Formats 3G SDI Output as Level A.
Formats 3G SDI Output as Level B.
Display Description
MENU # TITLE
PARAMETER VALUE
PARAMETER VALUE
Menu number and title.
Currently selected parameter value for this menu.
Higher range parameter value, when required.
Unity (default)
Adjust
All 16 SDI1 audio input channels are set to 0.0 dB. Individual channel
adjustment menus are hidden.
Each of the 16 SDI1 audio input channel adjusted values are applied
to the audio processor, and the individual channel adjustment
menus become available.
