FS1-X v1.1 www.aja.com 28
Install the optional fiber I/O modules by inserting them into the rectangular holes
marked Fiber on the back panel with the electrical connectors facing downward. Press
gently but firmly until the modules seat in the inside connectors. For additional
installation and operation details, see the instructions provided with the fiber modules.
FS1-X Chassis Installation
The following information will help you install the FS1-X chassis correctly.
Physical
Requirements for
Mounting the
Chassis
You can mount the FS1-X chassis in two ways:
• Rackmounting—attach the FS1-X (rear or front mounted) to a standard 19-inch wide
equipment rack. The chassis occupies only one vertical rack unit.
• Desktop—lay it on a horizontal flat surface.
Chassis Dimensions When planning the equipment location, consider the chassis dimensions:
• Height—1 rack unit, 1.75 inches (4.5 cm)
• Depth—16 inches (40.65 cm)
• Width—17.5 inches (44.45cm)
• Weight—7.85 pounds, 3.56 kilograms
Cabling and Cooling
Requirements
Observe these precautions when placing your FS1-X:
• Plan adequate space for cable routing from the back of the chassis. Ensure that cable
connectors are not stressed and cables are not bent or crimped.
• When rack mounting or stacking multiple FS1-X chassis, ensure adequate airspace for
cooling around the FS1-X units. Note the location of cooling vents on all equipment
next to the FS1-X and ensure none are obstructed.
NOTE: FS1-X units can be stacked vertically without limit as long as there is an adequate supply of
cool air around the FS1-X vents.
Power
Requirements
The FS1-X requires the following input voltage and power.
• Input Voltage—Chassis: autosensing 100VAC to 240VAC, 50/60Hz,
fully redundant with both power supplies diode isolated.
• Power Consumption—55 Watts, 60 Watts with FRC option (70 Watts maximum)
Caution!
Only AJA fiber optic I/O option modules may be inserted into the FS1-X Fiber slots. DO
NOT USE fiber modules from other manufacturers; they will damage the FS1-X
connectors and circuits.
