Rockwell Automation 1440-VDRP06-00RH XM-160/161/162 Direct Vibration Module - Manual (Page 88)

Publication GMSI10-UM025C-EN-P - August 2010
80 Specifications
Trend Buffer
Number or Records
Time Interval
Trigger
Post Trigger
Capacity
1 to 12 parameters
1 to 3600 seconds
Relay on the XM-441 Expansion Relay
module is activated, or by a trigger event
(for example, DeviceNet command from a
controller or host).
The data collected in the buffer is user
configurable in software.
Percent of trend that is to be acquired after
the trigger
170 to 2048 records
Alarms
Number
Operators
Hysteresis
Startup Inhibit
One per channel
Greater than
Less than
Inside range
Outside range
User configurable in software
Period: 0 to 1092 minutes, adjustable in 0.1
minute increments
Inhibit/multiplication function: Multiply by
N (0 to 10, 0 = Disarm)
Inhibit/multiplication initiated by:
DeviceNet command
Front terminal Setpoint Multiplier circuit
closure (XM-161 and XM-162 only)
Inhibit/multiplication terminated by:
Expired timer
DeviceNet command
Front terminal Setpoint Multiplier circuit
open (XM-161 and XM-162 only)
XM-160/161/162 Direct Vibration Technical Specifications
Product Feature Specification
