Publication GMSI10-UM025C-EN-P - August 2010
DeviceNet Objects 107
12 No Channel 6 Measurement Units USINT 0 = mils
1 = ips
2 = g
3 = psi
4 = volts
5 = mm/s
6 = µm
7 = Pa 0
13 No Relay 1 Alarm Identifier A USINT 0 = Alarm 1 (Ch1 value)
1 = Alarm 2 (Ch2 value)
2 = Alarm 3 (Ch3 value)
3 = Alarm 4 (Ch4 value)
4 = Alarm 5 (Ch5 value)
5 = Alarm 6 (Ch6 value) 0
14 No Relay 2 Alarm Identifier A USINT 0 = Alarm 1 (Ch1 value)
1 = Alarm 2 (Ch2 value)
2 = Alarm 3 (Ch3 value)
3 = Alarm 4 (Ch4 value)
4 = Alarm 5 (Ch5 value)
5 = Alarm 6 (Ch6 value) 0
15 No Relay 3 Alarm Identifier A USINT 0 = Alarm 1 (Ch1 value)
1 = Alarm 2 (Ch2 value)
2 = Alarm 3 (Ch3 value)
3 = Alarm 4 (Ch4 value)
4 = Alarm 5 (Ch5 value)
5 = Alarm 6 (Ch6 value) 0
16 No Relay 4 Alarm Identifier A USINT 0 = Alarm 1 (Ch1 value)
1 = Alarm 2 (Ch2 value)
2 = Alarm 3 (Ch3 value)
3 = Alarm 4 (Ch4 value)
4 = Alarm 5 (Ch5 value)
5 = Alarm 6 (Ch6 value) 0
17 No Relay 5 Alarm Identifier A USINT 0 = Alarm 1 (Ch1 value)
1 = Alarm 2 (Ch2 value)
2 = Alarm 3 (Ch3 value)
3 = Alarm 4 (Ch4 value)
4 = Alarm 5 (Ch5 value)
5 = Alarm 6 (Ch6 value) 0
18 No Relay 6 Alarm Identifier A USINT 0 = Alarm 1 (Ch1 value)
1 = Alarm 2 (Ch2 value)
2 = Alarm 3 (Ch3 value)
3 = Alarm 4 (Ch4 value)
4 = Alarm 5 (Ch5 value)
5 = Alarm 6 (Ch6 value) 0
19 No Relay 7 Alarm Identifier A USINT 0 = Alarm 1 (Ch1 value)
1 = Alarm 2 (Ch2 value)
2 = Alarm 3 (Ch3 value)
3 = Alarm 4 (Ch4 value)
4 = Alarm 5 (Ch5 value)
5 = Alarm 6 (Ch6 value) 0
Table C.20 Parameter Object Instances
Instance
Read
Only
Name Data Type Valid Values Default Value
