Publication GMSI10-UM025C-EN-P - August 2010
120 DeviceNet Objects
Services
1 Attributes can only be set while the device is in Program mode. See the description of the Device Mode Object
for more information.
Transducer Object
(Class ID 328
H
)
The Transducer Objective provides no class attributes.
11 Get/Set Alarm Identifier
B EPATH Identifies the second
alarm status the relay
monitors. See Parameter Object instances
21 to 28.
12 Get/Set Logic USINT Indicates the number of
associated alarms that
must have a status value
specified by Alarm Level
in order to activate the
relay. 0 = Ignore Alarm Identifier B
and activate the relay based on
the status of Alarm Identifier
A.
1 = Activate the relay if the
status of either Alarm
Identifier A or B matches any
of the statuses specified by
Alarm Level.
2 = Activate the relay if the
status of both Alarm Identifier
A and B match any of the
statuses specified by Alarm
Level.
14 Get Relay Installed BOOL Indicates whether an
actual relay is associated
with this instance. 0 = Not installed
1 = Installed
Table C.36 Relay Object Instance Attributes
Table C.37 Relay Object Services
Service
Code
Class/Instance Usage Name Description
05h Class/Instance Reset Resets latched relay.
0E
h
Class/Instance Get_Attribute_Single Returns a single attribute
10
h
Class/Instance Set_Attribute_Single
Sets a single attribute.
1
