Rockwell Automation 1440-VDRP06-00RH XM-160/161/162 Direct Vibration Module - Manual (Page 114)

Publication GMSI10-UM025C-EN-P - August 2010
106 DeviceNet Objects
6 No Transducer 6 Sensitivity Units USINT 0 = mils
1 = ips
2 = g
3 = psi
4 = volts
5 = mm/s
6 = µm
7 = Pa 0
7 No Channel 1 Measurement Units USINT 0 = mils
1 = ips
2 = g
3 = psi
4 = volts
5 = mm/s
6 = µm
7 = Pa 0
8 No Channel 2 Measurement Units USINT 0 = mils
1 = ips
2 = g
3 = psi
4 = volts
5 = mm/s
6 = µm
7 = Pa 0
9 No Channel 3 Measurement Units USINT 0 = mils
1 = ips
2 = g
3 = psi
4 = volts
5 = mm/s
6 = µm
7 = Pa 0
10 No Channel 4 Measurement Units USINT 0 = mils
1 = ips
2 = g
3 = psi
4 = volts
5 = mm/s
6 = µm
7 = Pa 0
11 No Channel 5 Measurement Units USINT 0 = mils
1 = ips
2 = g
3 = psi
4 = volts
5 = mm/s
6 = µm
7 = Pa 0
Table C.20 Parameter Object Instances
Instance
Read
Only
Name Data Type Valid Values Default Value
