Rockwell Automation 1440-VDRP06-00RH XM-160/161/162 Direct Vibration Module - Manual (Page 129)

Publication GMSI10-UM025C-EN-P - August 2010
DeviceNet Objects 121
Class Attributes
Instances
There are 6 instances of this object.
Attr ID
Access
Rule
Name Data Type Description Semantics
100 Get/Set Transducer
Power Type
(Ch1 & Ch2) USINT The type of power
supplied to the Ch1 and
Ch2 transducers. 0 = No power supplied
1 = Constant current (IEPE)
101 Get/Set Buffer Power
Mode USINT Indicates whether the
buffer power setting is
determined automatically
or manually. 0 = Manual mode
1 = Auto mode
102 Get/Set Buffer Power
Manual Mode
Setting USINT Determines the manual
setting of the buffer
power. 0 = Negative voltage
1 = Positive voltage
103 Get Buffer Power
Status USINT The actual buffer power
setting. 0 = Negative voltage
1 = Positive voltage
104 Get/Set IEPE Voltage
Boost USINT Determines whether to
use the IEPE voltage boost
feature. 0 = No boost
1 = Boost enabled, auto
2 = Boost enable, constant
105 Get/Set Transducer
Power Type
(Ch3 & Ch4) USINT The type of power
supplied to the Ch3 & Ch4
transducers. 0 = No power supplied
1 = Constant current (IEPE)
106 Get/Set Transducer
Power Type
(Ch5 & Ch6) USINT The type of power
supplied to the Ch5 & Ch6
transducers. 0 = No power supplied
1 = Constant current (IEPE)
Table C.38 Transducer Object Instance Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
3 Get DC Bias REAL The measured average DC
bias of the transducer
signal in volts. Volts
4 Get Status BOOL Indicates whether a
transducer fault exists
(the measured DC Bias is
outside the range
specified by Fault High
and Low). 0 = No fault
1 = Transducer fault exists
5 Get/Set Sensitivity
Value REAL Value of the sensitivity of
the transducer in
millivolts per Sensitivity
Units.
