62 Configuration Parameters
Channel Signal Processing
Parameters
The channel signal processing parameters determine the signal processing that
will be performed on the input signals. Use these parameters to select the
output data units, full scale settings, and the low cutoff frequency.
There are six instances of the signal processing parameters, one for each
channel.
Channel Signal Processing Parameters
Parameter Name
Description
Values/Comments
Output Data Unit
The data units of the measured values.
The available options depend on the
Eng. Units selection. See page
60.
Full Scale
The maximum vibration level expected to be
processed by the channel. This value is used to
determine the analog hardware range
(programmable gain settings).
Setting the full scale to a greater value allows the
channel to handle greater measurement levels
without saturating or clipping. Setting the full scale
value to a lesser value allows the measurement to
have greater resolution.
The full scale should be set to a value greater than
the maximum expected vibration level and/or the
value of the Danger alarm. Typical setting: 1.5 to 2
times greater.
Same measurement unit as Output
Data Unit selection for the specified
channel.
Eng. Units
Output Data
Unit Options
g
g
ips
mm/sec
ips or mm/sec
ips
mil
mm/sec
um
mils or um
mils
um
Volt
volt
Pa or psi
Pa
psi
