Rockwell Automation 1440-VDRP06-00RH XM-160/161/162 Direct Vibration Module - Manual (Page 27)

Publication GMSI10-UM025C-EN-P - August 2010
Installing the XM-160/161/162 Direct Vibration Module 19
34 No Connection 4-20mA 1...3 V+ GND/COM XM-161 channel 1, 2, & 3 4-20mA positive voltage supply
input (4-20mA loops returned directly to external power
source)
XM-162 circuit ground (Relay Reset and SetPtMult switch
return)
35 No Connection 4-20mA 1...3 V+ GND/COM XM-161 channel 1, 2, & 3 4-20mA positive voltage supply
input (4-20mA loops returned directly to external power
source)
XM-162 circuit ground (Relay Reset and SetPtMult switch
return)
36 No Connection Relay Reset Relay reset switch input
Switch returned to 24V GND (or signal common)
37 +24V In Connection to external +24V power supply, positive side
38 24V Common Connection to external +24V power supply, negative side
(internally DC-coupled to circuit ground)
39 Reserved
40 Common Internally DC-coupled to circuit ground
41 Chassis Connection to DIN rail ground spring or panel mounting hole
42 Chassis Connection to DIN rail ground spring or panel mounting hole
43 Chassis Connection to DIN rail ground spring or panel mounting hole
44 CAN_High DeviceNet bus connection, high differential (white wire)
45 CAN_Low DeviceNet bus connection, low differential (blue wire)
46 CAN Shield DeviceNet bus connection to chassis ground (bare wire)
47 DNet V (+) DeviceNet bus power input, positive side (red wire)
48 DNet V (-) DeviceNet bus power input, negative side (black wire)
49 No Connection SetPtMult Switch input to activate Setpoint Multiplier
Switch returned to 24V GND (or signal common)
50 No Connection 4-20mA 4...6 V+ GND/COM XM-161 channel 4, 5, & 6 4-20mA positive voltage supply
input (4-20mA loops returned directly to external power
source)
XM-162 circuit ground (Relay Reset and SetPtMult switch
return)
51 No Connection 4-20mA 4...6 V+ GND/COM XM-161 channel 4, 5, & 6 4-20mA positive voltage supply
input (4-20mA loops returned directly to external power
source)
XM-162 circuit ground (Relay Reset and SetPtMult switch
return)
Terminal Block Assignments
Name
No. XM-160 XM-161 XM-162 Description
