Rockwell Automation 1440-VDRP06-00RH XM-160/161/162 Direct Vibration Module User Manual
Page 87

Publication GMSI10-UM025C-EN-P - August 2010
Specifications 79
Indicators
8 LEDs Module Status - red/green
Network Status - red/green
Channel 1 Status - yellow/red
Channel 2 Status - yellow/red
Channel 3 Status - yellow/red
Channel 4 Status - yellow/red
Channel 5 Status - yellow/red
Channel 6 Status - yellow/red
Vibration Measurement & Signal
Conditioning
A/D Conversion
Resolution
Accuracy
Units
Range
Low Pass Filter
High Pass Filter
Additional Overall Low Pass Filter
Integrator
Overall Level
12 bits
0.05% of full scale
Max: ±5% of full scale 3Hz to 1kHz,
+5/-10% 1kHz to 5kHz
Typical: ±1% of full scale
volts g
ips mm/s
mils um
psi Pa
0 to 2ips RMS (integrated 100mV/g accel @
1kHz), 0 to 20g RMS (100mV/g accel), 0 to
15.6mils peak (200mV/mil probe)
1kHz or 5kHz selectable, 2-pole 0.1dB
Chebyshev (-0.1dB @ fo)
3.0Hz or 10.0Hz selectable, 2-pole 0.1dB
Chebyshev (-0.1dB @ fo)
Single pole, -3dB @ 10kHz (down 10% @
5kHz)
Single stage selectable, -0.3dB @ 3Hz
RMS
Peak (true or calculated)
Peak to Peak (true or calculated)
DC Bias (Gap) Voltage
Measurement
Low Pass Filter
Range
Accuracy
Resolution
Single pole, -3dB @ 335Hz
-24V dc to +24V dc
Max: ±5% of full scale (48V dc)
Typical: ±1% of full scale
47mV
XM-160/161/162 Direct Vibration Technical Specifications
Product Feature
Specification
