Rockwell Automation 1440-VDRP06-00RH XM-160/161/162 Direct Vibration Module - Manual (Page 125)

Publication GMSI10-UM025C-EN-P - August 2010
DeviceNet Objects 117
Class Attributes
Instances
There are 6 instances of this object
Instance Attributes
Table C.32 Overall Object Class Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
100 Get/Set Measurement WORD The measurement (or
calculation) performed to
produce the Overall
Value. 0 = RMS
1 = RMS peak
2 = RMS pk-to-pk
3 = peak
4 = peak-to-peak
5 = 255 reserved
Table C.33 Overall Measurement Object Class Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
3 Get Overall Value REAL Measured value The output value of the
measurement performed by
Overall Measurement Object on
the input signal. The result of
the measurement process
specified by Measurement is
converted to the units specified
by Data Units to produce the
Overall Value.
4 Get Status BOOL Indicates if a fault or
alarm has occurred. 0 = Operating without alarms or
faults.
1 = Alarm of fault condition
exists. The Overall Value
attribute may not represent the
actual field value.
5 Get Data Units ENGUNIT The units context of the
Overall Value attribute. This setting is determined by the
Channel Object’s Output Data
Units attribute (see page 114).
7 Get/Set Time Constant REAL The detection time
constant associated with
the output smoothing
filter (for the RMS and DC
meters), or the decay rate
of the peak meters. Must be greater than zero.
