Publication GMSI10-UM025C-EN-P - August 2010
DeviceNet Objects 103
Services
Discrete Input Point Object
(Class ID 08
H
)
The Discrete Input Point Object stores information about the value of the
Setpoint Multiplier signal.
Class Attributes
Instance Attributes
Table C.15 Connection Object Services
Service
Code
Class/Instance Usage Name
05
h
Instance Reset
0E
h
Instance Get_Attribute_Single
10
h
Instance Set_Attribute_Single
Table C.16 Discrete Input Object Class Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
1 Get Revision UINT Revision of the
implemented object. 2
Table C.17 Discrete Input Object Instance Attributes
Attr ID Access
Rule Name Data Type Description Semantics
3 Get Value BOOL Setpoint Multiplier 0 = Off
1 = On
199 Set Backdoor
Service USINT Setting this attribute is
equivalent to requesting
the specified service. Set to one of the
following values to
perform the
specified service:
0x32 = Open
0x33 = Close
