Publication GMSI10-UM025C-EN-P - August 2010
DeviceNet Objects 97
Assembly Object
(Class ID 04
H
)
The Assembly Object binds attributes of multiple objects to allow data to or
from each object to be sent or received in a single message.
The XM-160, XM-161, and XM-162 modules provide both static and dynamic
assemblies.
Class Attribute
Instances
Instance Attributes
Table C.6 Assembly Object Class Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
1 Get Revision UINT Revision of the
implemented object. 2
Table C.7 Assembly Object Instances
Instance Name Type Description
100 Default COS Message Input Alarm and Relay Status values
101 Default Poll Response
Message Input Measurement values
199 Alternate Dynamic Poll
Response Message Input User configurable
measurement values and
configuration parameters
Table C.8 Assembly Object Instance Attributes
Attr ID
Access
Rule
Name Data Type Value
1 Get Number of Members in list UINT Only supported for Dynamic Assembly
instance
