46 Rockwell Automation Publication 2080-UM001D-EN-E - September 2012
Appendix A Specifications
Non-isolated AC Inputs (2080-LC10-12AWA)
Attribute Value
On-state voltage, nom 120/240V AC
On-state voltage, min 79V AC
On-state voltage, max 265V AC
Off-state voltage, max 40V AC
Off-state current, max 0.095 mA
Operating frequency, nom 50/60 Hz
Input impedence 423.7 k
Ω
Operating frequency 47…63 Hz
Isolated AC Inputs (2080-LC10-12QWB, 2080-LC10-12QBB, 2080-LC10-DWD)
(Inputs 0…3)
Attribute Value
On-state voltage, nom 12/24V AC @ 50/60 Hz
Off-state voltage, min 4V AC @ 50/60Hz
Operating frequency, nom 50/60 Hz
DC Inputs (2080-LC10-12QWB, 2080-LC10-12QBB, 2080-LC10-12DWD)
Attribute Non-isolated, shared with analog inputs
(Inputs 4…7)
Isolated
(Inputs 0…3)
Voltage category 24V DC sink/source
On-state voltage, nom 12/24V DC
On-state voltage, min 9.8V DC
On-state voltage, max 28.8V DC
Off-state voltage, max 5V DC
Off-state current, max 0.5 mA 1.5 mA
On-state current, min 0.75 mA @ 10.8V DC
1.0 mA @ 15V DC 1.8 mA @ 10.8V DC
2.7 mA @ 15 V DC
On-state current, nom 2.1 mA @ 24V DC 6 mA @ 24V DC
On-state current, max 2.7 mA @ 28.8V DC 7.5 mA @ 28.8V DC
Nominal impedance 14.1 k
Ω
(non-isolated) 3.74 k
Ω
(isolated)
IEC input compatibility Type 1 Type 3
