Rockwell Automation Publication 2080-UM001D-EN-E - September 2012

27

Troubleshooting Chapter 5

0xF010

The user program contains a function/
function block that is not supported by
the Micro800 controller.

Perform the following:

Modify the program so that all functions/function blocks are supported by the

Micro800 controller.

Build and download the program using Connected Components Workbench.

Put the Micro800 controller on Run mode.

0xF014

A memory module memory error
occurred.

Reprogram the memory module. If the error persists, replace the memory module.

0xF015

An unexpected software error occurred.

Perform the following:
1. Cycle power on your Micro800 controller.
2. Build and download your program using Connected Components Workbench, and

then reinitialize any necessary data.

3. Start up your system.
See

Wire Your Controller on page 17

.

0xF016

An unexpected hardware error occurred.

Perform the following:
1. Cycle power on your Micro800 controller.
2. Build and download your program using Connected Components Workbench, and

then reinitialize any necessary data.

3. Start up your system.
See

Wire Your Controller on page 17

.

0xF020

The base hardware faulted or is
incompatible with the Micro800
controller’s firmware revision.

Perform one of the following:

Upgrade the Micro800 controller’s firmware revision using ControlFlash.

Replace the Micro800 controller.

Contact your local Rockwell Automation technical support representative for more

information about firmware revisions for your Micro800 controller. For more
information on firmware revision compatibility, go to

http://www.rockwellautomation.com/support/firmware.html

0xF021

The I/O configuration in the user program
is invalid or does not exist in the
Micro800 controller.

Perform the following:

Verify that you have selected the correct Micro800 controller from the Device

Toolbox.

Correct the plug-in I/O module configuration in the user program to match that of the

actual hardware configuration.

Recompile and reload the program.

Put the Micro800 controller on Run mode.

If the error persists, be sure to use Connected Components Workbench programming

software to develop and download the program.

0xF022

The user program in the memory module
is incompatible with the Micro800
controller’s firmware revision.

Perform one of the following:

Upgrade the Micro800 controller’s firmware revision using ControlFlash to be

compatible with the memory module.

Replace the memory module.

Contact your local Rockwell Automation technical support representative for more

information about firmware revisions for your Micro800 controller. For more
information on firmware revision compatibility, go to

http://www.rockwellautomation.com/support/firmware.html

List of Error Codes for Micro800 controllers

Error Code

Description

Recommended Action
