Publication 1756-UM007C-EN-P - November 2011
82 Module Diagnostics
RSLogix 5000 Diagnostics
In addition to the Status Indicator display on the module, RSLogix 5000
software will alert you to fault conditions.
See page 85 for details on status indicators.
Fault conditions in RSLogix 5000 software are reported in one of four ways.
• Warning signal on the main window next to the module - This occurs
when the connection to the module is broken.
• Fault message in a window’s status line.
• Notification in the Tag Editor - General module faults also are reported
in the Tag Editor. Diagnostic faults are reported only in the Tag Editor.
• Status on the Module Info tab.
16#0051, 16#0052
BADSCALE - Occurs if you take any of the following
actions in the Counter/Frequency modes:
• Program a value greater than 2000 in Frequency mode
• Program a value that is not an integer multiple of 10 in
Frequency mode
• Program a value whose scaler is not equal to 0
Occurs in Period Rate/Continuous Rate modes if
the scaler is not 0, 1, 2, 4, 8, 16, 32, 64, 128, 256
Output Configuration Errors
Error Code Definition
16#0061, 16#0062,
16#0063, 16#0064
BADTIE - Occurs if you attempt to tie an output to a
nonexistent counter or if you attempt to tie the output to two
counters; valid entries are 0x0, 0x1,or 0x2
16#0071, 16#0072,
16#0073, 16#0074
BADFAULT - Occurs if you configure the module for
something other than On, Off, or Continue or if the
1756-HSC module receives a communication fault in Run
mode; valid entries are 0x0, 0x1, and 0x2
16#0081, 16#0082,
16#0083, 16#0084
BADPROG - Occurs if you configure the module for
something other than On, Off, or Continue when
transitioning from Run mode to Program mode; valid entries
are 0x0, 0x1, and 0x2
16#0091, 16#0092,
16#0093, 16#0094 BADWINDOW - Occurs if the On/Off values are greater
than the 0xfffffe value
Counter Configuration Errors
Error Code Definition
