34 Frequency Modes
The inverse relationship of the increase in frequency and decrease in sampled
pulses is shown in the table.
Inverse Relationship of Frequency and Sampled Pulses
Input Frequency
at Z-Input
Scaler Value No. of 4 MHz Pulses
in Present Value Tag
2 Hz
1 1,000,000
2 2,000,000
4 4,000,000
5 Hz
1 400,000
2 800,000
4 1,600,000
10 Hz
1 200,000
2 400,000
4 800,000
20 Hz
1 100,000
2 200,000
4 400,000
50 Hz
1 40,000
2 80,000
4 160,000
100 Hz
1 20,000
2 40,000
4 80,000
200 Hz
1 10,000
2 20,000
4 40,000
500 Hz
1 4,000
2 8,000
4 16,000
