Configure the 1756-HSC Module 65
2. Click OK.
Set Up Counter
Configuration
The Counter Configuration tab (on the Module Properties dialog box) is
identical for both the HSC-Data and HSC Data-extended Comm Formats.
However, the HSC Data-extended format includes the addition of the Period
Rate and Continuous Rate frequency selections in the Operational Mode
pull-down menu.
Be sure to select only features that are compatible with your selected
communication format. See
page 66 for Counter Configuration tab
descriptions.
The Operational modes determine how the incoming pulses are counted. The
Storage modes allow the count values to be manipulated if the application
requires storage of the accumulated count value.
Follow these steps to choose Counter and Storage mode options.
1. On the Modules Properties dialog box, click the Counter
Configuration tab.
Use Unicast Connection on EtherNet/IP Displays only for 1756-HSC modules
using RSLogix 5000 software version 18
in a remote EtherNet/IP chassis. Use the
default checkbox if there are no other
controllers in ‘Listen’ mode.
Clear the box if there are other
‘listening’ controllers in the system.
Module Fault The fault box is empty if you are offline.
The type of fault displays in the text box
if a fault occurs when the 1756-HSC
module is online.
Field Description
TIP The different operational modes are detailed on page 17 in
Chapter 2.
