70 Configure the 1756-HSC Module
3. Click OK.
First Value Output Turns ON Type values to turn the selected output
On and Off, respectively. Each pair (First
Value, Second Value) can be assigned to
an output.
The values can be set for the rising or
falling edge of the window depending
on whether the Invert Z Value is active
for an operational mode. For example, a
pulse count could turn On at 100 counts
and end at 200 counts, or turn Off at 100
counts and turn back On at 200 counts.
First Value Output Turns OFF
Second Value Output Turns ON
Second Value Output Turns OFF
Communications Failure
When communications fail in Program
Mode
Select the output’s status if
communication is severed between the
module and its owner-controller.
Field Description
