102 1756-HSC Module History
4. Re-enter the 1756-HSC module configuration data that you wrote down
in step 1 that matches the generic profile configuration.
5. Do a global search and replace of the prefix for each of the generic
references with the tag prefix for the full profile.
Examples:
• Replace ‘HSC_IN’ with ‘Local:3.I’ (for a local module in slot 3).
• Replace ‘HSC_OUT’ with ‘Local:3:O’ (for a local module in slot 3).
• Replace ‘HSC_CONFIG’ with ‘Local:3:C’ (for a local module in slot 3).
6. Download your program.
7. Go to Run mode to execute the ladder logic.
Edit Thin Profile Tags
Use this section if you want your 1756-HSC module running the original
functionality and your version of RSLogix 5000 software is earlier than
version 15. Original functionality includes the Counter, Encoder x1,
Encoder x4, and Frequency modes.
RSLogix 5000 software earlier than version 15 does not have a user-interface
for data entry. A thin profile requires that you manually enter operational
modes and output settings in the Controller Tags window.
IMPORTANT
A global search and replace is needed only for those tags
referenced in ladder logic. For example, if there is no
configuration tag referenced in ladder logic, it’s not
necessary to perform a search and replace on the .C tags.
IMPORTANT
Firmware revision 2.
x requires that both profiles (thin/full) for
software versions 15…17 not have electronic keying set to
Exact Match for compatibility with the 1.
x firmware revision.
You must upgrade to version 18 or later if Exact Match is
required for electronic keying.
