81 Publication 1756-UM007C-EN-P - November 2011
Chapter
6
Module Diagnostics
Introduction
This chapter describes error codes and fault conditions to help you
troubleshoot the 1756-HSC module.
1756-HSC Error Codes
Errors are displayed on the Connection tab of the Module Properties dialog
box in RSLogix 5000 software and in the .EXERR field of the message
variable when you reconfigure the module.
The final number of each code represents the channel number that is reporting
the error: 1 = channel 0 and 2 = channel 1.
For example, code 16#0011 means that a BADCOUNT has occurred on
channel 0.
The following table lists possible errors on your 1756-HSC module.
Topic Page
1756-HSC Error Codes 81
RSLogix 5000 Diagnostics 82
Troubleshoot the 1756-HSC Module 84
Counter Configuration Errors
Error Code Definition
16#0011, 16#0012
BADCOUNT - Occurs if you set the operational mode to a
value of seven or greater
16#0021, 16#0022
BADSTORE - Occurs if you set the Storage mode to a value
of six or greater or if the Storage mode is set to a nonzero
value in Frequency mode
16#0031, 16#0032 BADROLL - Occurs if you program a nonzero value in Period
Rate/Continuous Rate frequency modes or if you program a
value greater than 0xfffffe
16#0041, 16#0042
BADPRESET - Occurs if you program a nonzero value in
Period Rate/Continuous Rate frequency modes or if you
program a value equal to or greater than the rollover value
