TROUBLESHOOTING 10-43
1557-UM050F-EN-P – June 2013
Drive Faults
Fault
Code #
WARNING
MESSAGE
Description
F441 M3C shorted Thyristor 3C in Machine Converter is shorted.
F442 M3B shorted Thyristor 3B in Machine Converter is shorted.
F443 M3D shorted Thyristor 3D in Machine Converter is shorted.
F444 M3E shorted Thyristor 3E in Machine Converter is shorted.
F445 M3F shorted Thyristor 3F in Machine Converter is shorted.
F446 M3G shorted Thyristor 3G in Machine Converter is shorted.
F447 M3H shorted Thyristor 3H in Machine Converter is shorted.
Drive Faults
Fault
Code #
WARNING
MESSAGE
Description
F448 M4A open Thyristor 4A in Machine Converter is open.
F449 M4C open Thyristor 4C in Machine Converter is open.
F450 M4B open Thyristor 4B in Machine Converter is open.
F451 M4D open Thyristor 4D in Machine Converter is open.
F452 M4E open Thyristor 4E in Machine Converter is open.
F453 M4F open Thyristor 4F in Machine Converter is open.
F454 M4G open Thyristor 4G in Machine Converter is open.
F455 M4H open Thyristor 4H in Machine Converter is open.
F456 M4A shorted Thyristor 4A in Machine Converter is shorted.
F457 M4C shorted Thyristor 4C in Machine Converter is shorted.
F458 M4B shorted Thyristor 4B in Machine Converter is shorted.
F459 M4D shorted Thyristor 4D in Machine Converter is shorted.
F460 M4E shorted Thyristor 4E in Machine Converter is shorted.
F461 M4F shorted Thyristor 4F in Machine Converter is shorted.
F462 M4G shorted Thyristor 4G in Machine Converter is shorted.
F463 M4H shorted Thyristor 4H in Machine Converter is shorted.
F464 M5A open Thyristor 5A in Machine Converter is open.
F465 M5C open Thyristor 5C in Machine Converter is open.
F466 M5B open Thyristor 5B in Machine Converter is open.
F467 M5D open Thyristor 5D in Machine Converter is open.
F468 M5E open Thyristor 5E in Machine Converter is open.
F469 M5F open Thyristor 5F in Machine Converter is open.
F470 M5G open Thyristor 5G in Machine Converter is open.
F471 M5H open Thyristor 5H in Machine Converter is open.
F472 M5A shorted Thyristor 5A in Machine Converter is shorted.
F473 M5C shorted Thyristor 5C in Machine Converter is shorted.
F474 M5B shorted Thyristor 5B in Machine Converter is shorted.
F475 M5D shorted Thyristor 5D in Machine Converter is shorted.
F476 M5E shorted Thyristor 5E in Machine Converter is shorted.
F477 M5F shorted Thyristor 5F in Machine Converter is shorted.
F478 M5G shorted Thyristor 5G in Machine Converter is shorted.
F479 M5H shorted Thyristor 5H in Machine Converter is shorted.
F480 M6A open Thyristor 6A in Machine Converter is open.
F481 M6C open Thyristor 6C in Machine Converter is open.
F482 M6B open Thyristor 6B in Machine Converter is open.
F483 M6D open Thyristor 6D in Machine Converter is open.
F484 M6E open Thyristor 6E in Machine Converter is open.
