6-62 PARAMETER AND VARIABLE DESCRIPTIONS
1557-UM050F-EN-P – June 2013
17
Control Mask Parameters
Name Minimum Maximum Default Units
241 Logic Mask 00H FFH FFH
242 Local Mask 00H FFH FFH
243 Start Mask 00H FFH FFH
244 Direction Mask 00H FFH FFH
245 Jog Mask 00H FFH FFH
247 Fault Reset Mask 00H FFH FFH
248 Speed Command Mask 00H FFH FFH
249 Sync Transfer Mask 00H FFH FFH
18
Status Variables
Name Minimum Maximum 1.0V = Units
257 Logic Command 0000H FFFFH NA Hex
258 Logic Status 1 0000H FFFFH NA Hex
260 Local Discrete Inputs 0000H FFFFH NA Hex
261 Local Discrete Outputs 0000H FFFFH NA Hex
262 Pass Code 0 65535 NA
19
Speed Command Variables
Name Minimum Maximum 1.0V = Units
273 Speed Command 0 -100.0 100.0 12.8 Hz
274 Speed Command 8 -100.0 100.0 12.8 Hz
275 Speed Command 9 -100.0 100.0 12.8 Hz
276 Speed Command Input -100.0 100.0 12.8 Hz
277 Speed Command -100.0 100.0 12.8 Hz
278 Speed Reference -100.0 100.0 12.8 Hz
20
Speed Control Variables
Name Minimum Maximum 1.0V = Units
289 Speed Feedback -100.0 100.0 12.8 Hz
290 Speed Error -10.00 10.00 0.2 Hz
291 Torque Reference -1.500 1.500 0.2
292 Isq Command -2.000 2.000 0.2 pu
293 Icq Command -1.000 1.000 0.2 pu
294 Iy Command -2.000 2.000 0.2 pu
295 PWM Pulse Number 1 361 NA
297 Sync Regulator Error -180 180 18 deg
298 Sync Regulator Output -10.00 10.00 0.2 Hz
