PARAMETER AND VARIABLE DESCRIPTIONS 6-63
1557-UM050F-EN-P – June 2013
21
Flux Control Variables
Name Minimum Maximum 1.0V = Units
305 Flux Reference 0.000 1.500 0.2 pu
306 Flux Feedback 0.000 1.500 0.2 pu
307 Flux Error -1.500 1.500 0.2 pu
308 Isd Command 0 0.000 1.000 0.2 pu
309 Isd Command 1 -1.000 1.000 0.2 pu
310 Isd Command -1.000 1.000 0.2 pu
311 Icd Command 0.000 1.000 0.2 pu
312 Ix Command -1.000 1.000 0.2 pu
314 I Field Command 0.000 1.000 0.1 pu
22
Current Control Variables
Name Minimum Maximum 1.0V = Units
321 Idc Reference 0.000 2.000 0.2 pu
322 Idc Feedback 0.000 2.000 0.2 pu
323 Idc Error -2.000 2.000 0.2 pu
324 V Line 0.000 1.500 0.2 pu
326 Vdc Reference -1.000 1.000 0.1
327 Alpha Line 0.0 180.0 36 deg
328 Alpha Machine 0.0 359.9 36 deg
23
Motor Model Variables
Name Minimum Maximum 1.0V = Units
337 Stator Frequency 0.0 100.0 12.8 Hz
338 Isd -2.000 2.000 0.2 pu
339 Isq -2.000 2.000 0.2 pu
340 I Stator 0.000 2.000 0.2 pu
341 Flux from Current 0.000 1.500 0.2 pu
342 Flux from Voltage 0.000 1.500 0.2 pu
343 Slip Frequency -2.00 2.00 3.2 Hz
344 V Stator 0.000 1.500 0.2 pu
345 Torque -1.500 1.500 0.2
346 Motor Power -1.500 1.500 0.2
347 V Neutral Motor 0.000 1.500 0.2 pu
348 Tach Feedback -100.0 100.0 12.8 Hz
