COMMISSIONING 9-9
1557-UM050F-EN-P – June 2013
Analog Outputs
Port 1 – Analog 1L
Port 2 – Analog 2L
Port 3 – Analog 3L
Port 4 – Analog 4L
Port 5 – Analog 1M
Port 6 – Analog 2M
Port 7 – Analog 3M
Port 8 – Analog 4M
Port 9 – Analog 5L
Port 10 – Analog 6L
Port 11 – Analog 5M
Port 12 – Analog 6M
PLC Inputs
Port1 – Link A1
Port 2 – Link A2
Port 3 – Link B1
Port 4 – Link B2
Port 5 – Link C1
Port 6 – Link C2
Port 7 – Link D1
Port 8 – Link D2
PLC Outputs
Port 1 – Link A1
Port 2 – Link A2
Port 3 – Link B1
Port 4 – Link B2
Port 5 – Link C1
Port 6 – Link C2
Port 7 – Link D1
Port 8 – Link D2
