Troubleshooting
8-3
SCANport Status LED States
The LED furthest from the DeviceNet connector is the SCANport
Status LED, and is labeled “SP.” It indicates the status of the
SCANport connection, and functions as follows:
LED Viewed:
If:
State:
Indicates
Action:
SCANport
Status LED
LED is off
Not powered
No power
Ensure that the connected SCANport device is powered
and that the product is connected to the adapter.
LED is flashing
green
Online/ I/O
connecting
Requesting I/O
connections or no I/O
is selected
No action needed. Adapter is establishing one or more of
the I/O connections with the SCANport device.
LED is steady green
I/O operational
One or more
connections
established
No action needed.
LED is flashing red
Configuration fault
SCANport problem:
No communications
seen from the
SCANport device to
request connections
1. Reseat cable properly.
2. Replace cable.
LED is steady red
Link failure
SCANport failure:
Poor cable connection
does not allow proper
port identification or
the SCANport device
isn’t allowing the
configured I/O
connections.
1. Check all SCANport cables and connections to the
SCANport device.
2. Ensure datalinks are not enabled on a product that
doesn’t support datalinks. Or, ensure that a particular
datalink is not already being used by another adapter on
the same SCANport device.
In either case, the adapter must be properly configured
and power cycled after the problem is fixed.
LED is steady
orange
Failed SCANport
compatibility test
Call Rockwell Automation support.
