DeviceNet Objects C-3
Instance Attributes
Common Services
Get_Attribute_All Response
None supported.
Attribute ID Access Rule Name Data Type Description
1 Get Vendor ID UINT Identification of each vendor by number.
1 = Allen-Bradley
2 Get Device Type UINT Indication of general type of product.
0x69 = Sub-Component
0x6F = SCANport Device
3 Get Product Code UINT Identification of a particular product of an individual vendor.
0xXX02 = 1336 PLUS 0.5 – 10 HP -S/B 0xXX02
0xXX03 = 1336 PLUS 7.5 – 800 HP -S/B 0xXX03
0xXX07 = 1336 PLUS II -S/B 0xXX07
0xXX10 = 1336 FORCE w/ PLC Adapter -S/B 0xXX10
0xXX11 = 2364F RGU -S/B 0xXX11
0xXX12 = 1394 Motion Drive -S/B 0xXX12
0xXX13 = 1557 Medium Voltage AC Drive -S/B 0xXX13
0xXX14 =193 SMP-3 -S/B 0xXX14
0xXX15 = 150 SMC Dialog Plus -S/B 0xXX15
0xXX17 = 1305 AC Drive -S/B 0xXX17
0xXX18 = 1397 DC Drive -S/B 0xXX18
0xXX19 = 1336 VSC -S/B 0xXX19
0xXX20 = 1336T Force w/ Std Adapter -S/B 0xXX20
0xXX22 = 1336 IMPACT -S/B 0xXX22
Note: The high byte of each code indicates a particular size or
configuration within a product family.
4 Get Revision STRUCT of Revision of the item that this instance of the Identity Object
represents.
Value varies based on product.
Major Revision USINT
Minor Revision USINT
5 Get Status WORD Summary status of product.
Value varies based on product.
6 Get Serial Number UDINT Serial number of product.
Value varies based on product.
7 Get Product Name SHORT_
STRING
Human readable identification.
Value varies based on product.
Service Code
Implemented for:
Service Name
Class Instance
0x05 Yes No Reset
0x0E Yes Yes Get_Attribute_Single
0x10 No No Set_Attribute_Single
0x11 Yes N/A Find_Next_Obj_Instance
