Chapter 6
Troubleshooting
6–3
Action: Check DIP switch settings and reset drive, if condition
persists replace adapter board.
Message: CA–35–ADD FUNC BLK OVERFLOW
Fault Type: Warning/Soft
Cause:
The Add function block output value has overflowed.
Action: Check range on inputs, gains values, and offset values for
ADD block.
Message: CA–36–MULT1 FUNC BLK OVERFLOW
Fault Type: Warning/Soft
Cause:
The Multiplication function block output value has
overflowed.
Action: Check input range and gain value.
Message: CA–37–MULT2 FUNC BLK OVERFLOW
Fault Type: Warning/Soft
Cause:
The Multiplication 2 function block output value has
overflowed.
Action: Check input range and gain value.
Message: CA–44–ADAPTER PROCESSOR FAULT
Fault Type: Hard
Cause:
Adapter internal diagnostic malfunction.
Action: Check dip switch settings and reset drive, if condition persists
replace adapter board.
Message: CA–45–ADAPTER PROCESSOR FAULT
Fault Type: Hard
Cause:
Adapter internal diagnostic malfunction.
Action: Check dip switch settings and reset drive, if condition persists
replace adapter board.
Message: CA–50–ADAPTER PROCESSOR FAULT
CA–51–ADAPTER PROCESSOR FAULT
CA–52–ADAPTER PROCESSOR FAULT
Fault Type: Hard
Cause:
Adapter internal diagnostic malfunction.
Action: Check dip switch settings and reset drive, if condition persists
replace adapter board.
Message: CA–53–CHANNEL A BT FAIL
CA–54–CHANNEL B BT FAIL
Fault Type: Warning
Cause:
Unable to complete RIO block transfer.
Action: Resend block transfer, if condition persists, replace adapter
board.
