Rockwell Automation 1395 Multi-Comm Hardware/Software User Manual
Page 117
Chapter 8
Reference
8–22
Table 8-C. RIO Parameter Summary (cont.)
DEC
525
526
537
538
575
576
587
588
HEX
NAME
UNITS
INIT
MIN
MAX
EE
FUNCTION
PORT
20DH
20EH
219H
21AH
23FH
240H
241H
24CH
B>ChA RIO Flt S1
B>Redund Chan No
B>ChB RIO Flt S1
B>Redund Chan No
A>ChA RIO Flt S1
A>Redund Chan No
A>ChB RIO Flt S1
A>Redund Chan No
B
B
B
B
A
A
A
A
None
None
None
None
None
None
None
None
Setup
Setup
Setup
Setup
Setup
Setup
Setup
Setup
000B
0
000B
0
000B
0
000B
0
0000
0
0000
0
0000
0
0000
0
001F
1
001F
1
001F
1
001F
1
