Chapter 3

Configuration & Interfacing

3–53

NOTE: Word 4 of the BTR instruction is

broken down into two bytes. The High
byte contains the status bits per Table
3–H. The low byte contains the Drive
message length in bytes.

The “x” designator is a position holder. It could represent
parameter 150, 250, 350, etc. depending on which configura-
tion table is being sent.

BTR

0

0

See Table

8

WORD

1

2

3

4

Message Operation – The DOWNLOAD CONFIGURATION TABLE
function sends a listing of the desired Drive configuration links to the
Drive. This command is broken down into five groups of tables.

IMPORTANT: Drive configuration links will not be changed by the Drive
unless the following two conditions are met:

1. The Drive must not be running (i.e. the DC loop contactor must not be

energized).

2. The Drive receives the fifth block (function code 2564) of links.
