4 Chapter
4–1
Installation
Chapter Objective
This chapter is a detailed step-by-step procedure for the proper installation
of the Bulletin 1395 Multi-Communications Adapter Board. Procedures
performed in this chapter include:
S Unpacking and inspection
S Proper mounting
S Connection & Switch Settings
Receiving
It is your responsibility to thoroughly inspect the equipment before
accepting shipment from the freight company. You must take the
responsibility for noting any damage. Do Not accept shipment before
checking all items received against the purchase order, and noting any
missing or damaged items on the freight bill.
If any concealed damage is found later during unpacking, it is your
responsibility to notify the freight agent. Leave the shipping container
intact and request that the freight agent make a visual inspection of the
shipment.
!
ATTENTION: This drive contains ESD (Electrostatic Discharge)
sensitive parts and assemblies. Static control precautions are required
when installing, testing, servicing or repairing this assembly. Component
damage may result if ESD control procedures are not followed. If you
are not familiar with static control procedures, reference A-B publication
8000-4.5.2, Guarding Against Electrostatic Damage or any other
applicable ESD protection handbook.
Unpacking & Inspection
Remove all packing material from around the board. Before removing the
anti-static bag it should be noted that.the MCA Board is a static sensitive
device, and special precautions must be taken while handling the board.
The circuit board can be damaged by Electrostatic Discharge. It is possible
to make contact with an ESD sensitive component during installation
Therefore, personnel must be properly grounded. Grounding should be
accomplished with a wrist strap which is connected to an approved ground.
If the board will not be installed when it is unpacked, it should be stored in
a clean dry place in the anti-static bag. The storage temperature must be
between 0
°
C (32
°
F) and +60
°
(140
°
F) with a maximum humidity of 95%
non-condensing, to guard against damage to temperature sensitive
components.
