Chapter 8
Reference
8–29
Parameter 453 – [A>ChA RIO Out 4]
Parameter 353 – [B>ChA RIO Out 4]
Use: Channel A RIO Output word #4
Parameter Type: Fast Sink
Program Terminal Units: None
Minimum Value:
Maximum Value:
Default Value: None
Description: This parameter is a fast sink that provides the fourth word
or group of data to the PLC controller input image table. The data is
transferred to the PLC Controller by the RIO scanner every rack scan.
The value can be provided by the MCA board directly or by other Drive
functions through a configuration link. This parameter is only available
on channels that are setup as full or 3/4 racks.
Parameter 454 – [A>ChA RIO Out 5]
Parameter 354 – [B>ChA RIO Out 5]
Use: Channel A RIO Output word #5
Parameter Type: Fast Sink
Program Terminal Units: None
Minimum Value:
Maximum Value:
Default Value: None
Description: This parameter is a fast sink that provides the fifth word or
group of data to the PLC controller input image table. The data is
transferred to the PLC Controller by the RIO scanner every rack scan.
The value can be provided by the MCA board directly or by other Drive
functions through a configuration link. This parameter is only available
on channels that are setup as full or 3/4 racks.
Parameter 455 – [A>ChA RIO Out 6]
Parameter 355 – [B>ChA RIO Out 6]
Use: Channel A RIO Output word #6
Parameter Type: Fast Sink
Program Terminal Units: None
Minimum Value:
Maximum Value:
Default Value: None
Description: This parameter is a fast sink that provides the sixth word or
group of data to the PLC controller input image table. The data is
transferred to the PLC Controller by the RIO scanner every rack scan.
The value can be provided by the MCA board directly or by other Drive
functions through a configuration link. This parameter is only available
on channels that are setup as full racks.
