Rockwell Automation 1395 Multi-Comm Hardware/Software User Manual
Page 110

Chapter 8
Reference
8–15
Parameter 558 – [A>Add FB In 1]
Parameter 508 – [B>Add FB In 1]
Use: Specifies an input to the Add function block
Parameter Type: Setup
Program Terminal Units: None
Minimum Value: B–300/A–400
Maximum Value: B–503/A–553
Default Value: B–320/A–420
Description: This parameter specifies where the Add function block gets
one of its inputs. Input data can come from other functions on this
Adapter or from the Drive by using a CA Indirect parameter linked to the
desired information. A value outside the following ranges disables the
function block input.
CHAN B
CHAN A
300 – 319
400 – 419
350 – 369
450 – 469
500 – 503
550 – 553
Parameter 559 – [A>Add FB Gain 1]
Parameter 509 – [B>Add FB Gain 1]
Use: Specifies Add input #1 gain value
Parameter Type: Setup
Program Terminal Units: None
Minimum Value: –15.999
Maximum Value: 15.995
Default Value: 0
Description: This parameter specifies the Add input #1 gain value. The
gain value is multiplied by the input #1 data prior to the summation of all
block values.
Parameter 560 – [A>Add FB In 2]
Parameter 510 – [B>Add FB In 2]
Use: Specifies an input to the Add function block
Parameter Type: Setup
Program Terminal Units: None
Minimum Value: B–300/A–400
Maximum Value: B–503/A–553
Default Value: B–320/A–420
Description: This parameter specifies where the Add function block gets
one of its inputs. Input data can come from other functions on this
Adapter or from the Drive by using a CA Indirect parameter linked to the
desired information.
CHAN B
CHAN A
300 – 319
400 – 419
350 – 369
450 – 469
500 – 503
550 – 553
