Publication 1408-UM001B-EN-P - May 2008 93
Powermonitor 1000 Data Tables Appendix A
Parameters for Configurable Table
Parameter No. Parameter Name Description
0 None No Parameter.
1 Date: Year Refer to Date and Time Configuration table.
2 Date: Month
3 Date: Day
4 Time: Hour
5 Time: Minute
6 Time: Seconds
7 Time: Hundredths
8 Status Input States Refer to Discrete Results table.
9 Output Word
10 Wiring Status Refer to Wiring Diagnostics Results table.
11 Voltage Input Missing
12 Voltage Input Inverted
13 Current Input Missing
14 Current Input Inverted
15 Voltage Rotation
16 Current Rotation
17 Voltage Phase 1 Angle
18 Voltage Phase 1 Magnitude
19 Voltage Phase 2 Angle
20 Voltage Phase 2 Magnitude
21 Voltage Phase 3 Angle
22 Voltage Phase 3 Magnitude
23 Current Phase 1 Angle
24 Current Phase 1 Magnitude
25 Current Phase 2 Angle
26 Current Phase 2 Magnitude
27 Current Phase 3 Angle
28 Current Phase 3 Magnitude
29 L1 Current Refer to Volts, Amps, Frequency Results table.
30 L2 Current
31 L3 Current
32 Average Current
33 L1-N Volts
