Rockwell Automation 1408-EMxx PowerMonitor 1000 Unit User Manual
Page 59
Publication 1408-UM001B-EN-P - May 2008
59
Powermonitor 1000 Data Tables Appendix A
4
40505
Off Peak Days
65
0…127
•
•
•
This bit map field selects the off peak
days. OFF-PEAK days have only one rate
for billing.
Bit0= Sunday
Bit1= Monday
Bit2= Tuesday
Bit3= Wednesday
Bit4= Thursday
Bit5= Friday
Bit6= Saturday
Saturday and Sunday are default Off
Peak days.
5
40506
MID Peak AM
Hours
1792
0…
4095
•
•
•
This bit map selects any AM hours that
are designated as MID Peak. Example:
The hours from 8 AM to 11AM is
designated as bit 8 through bit 10 =
1792d.
Bit0= 12 AM…1 AM
Bit1= 1 AM…2 AM
Bit2= 2 AM…3 AM
…
…
Bit11= 11AM…12 AM
Default is 8 AM…11 AM
6
40507
MID Peak PM
Hours
120
0…
4095
•
•
•
This bit map selects any PM hours that
are designated as MID Peak. Example:
The hours from 3 PM to 7 PM is
designated as bit 3 through bit 6 = 120d.
Bit0= 12 PM…1 PM
Bit1= 1 PM…2 PM
Bit2= 2 PM…3 PM
…
…
Bit11= 11PM…12 PM
Default is 3 PM…7 PM
7
40508
ON Peak AM
Hours
2048
0…
4095
•
•
•
This bit map selects any AM hours that
are designated as ON Peak. Example:
The hours from 11AM to 12 PM is
designated as bit 11 = 2048d.
Bit0= 12 AM…1 AM
Bit1= 1 AM…2 AM
Bit2= 2 AM…3 AM
…
Bit11= 11AM…12 AM
Default is 11AM
Log Configuration
Element
No.
Modbus
Address
Element Name Default
Value
Range
TR1
TR2
EM1
EM2
EM3
Description
