Publication 1408-UM001B-EN-P - May 2008 81
Powermonitor 1000 Data Tables Appendix A
8 30909 Overall Status 0…16383 0 indicates normal operation. Each bit indicates a
different fault condition.
Bit 0 = Flash Memory
Bit 1 = SRAM
Bit 2 = NVRAM
Bit 3 = SPI Interface
Bit 4 = Real Time Clock
Bit 5 = Watchdog Timer
Bit 6 = Metering
Bit 7 = LCD Interface
Bit 8 = Serial Communications
Bit 9 = Ethernet Communications
Bit 10 = Error Log Full
9 30910 Flash Memory 0…511 0 indicates normal operation. Status bits are
Bit 0 = Overall status
Bit 1 = Boot code checksum
Bit 2 = Application code checksum
Bit 3 = Calibration data CRC
Bit 4 = No calibration data
Bit 5 = Wrong application FRN
Bit 6 = Invalid model type
Bit 7 = WIN mismatch
Bit 8 = missing upgrade block
10 30911 SRAM 0…1 0 indicates normal operation.
Bit 0 = Read/write test
11 30912 NVRAM 0…1 0 indicates normal operation.
Bit 0 = Read/write test
12 30913 SPI Interface 0…1 0 indicates normal operation.
Bit 0 = SPI device not responding
13 30914 Real Time Clock 0…3 0 indicates normal operation.
Bit 0 = RTC status
Bit 1 = Time Zone Set Failed
14 30915 Watchdog Timer 0…1 0 indicates normal operation.
Bit 0 = Watchdog time out
15 30916 Metering 0…1 0 indicates normal operation.
Bit 0 = Metering status
16 30917 LCD Interface 0…1 0 indicates normal operation.
Bit 0 = LCD Interface status
17 30918 Serial Communications 0…1 0 indicates normal operation.
Bit 0 = Serial Interface status
Unit Run Status Results
Element
No. Modbus
Address Element Name Range Description
