Rockwell Automation 1408-EMxx PowerMonitor 1000 Unit User Manual
Page 73
Publication 1408-UM001B-EN-P - May 2008
73
Powermonitor 1000 Data Tables Appendix A
4
30409-10
GWh Fwd
0…9,999,999
•
•
•
Forward gigawatt hours
5
30411-12
kWatth Fwd
0.000…999,999
•
•
•
Forward kilowatt hours
6
30413-14
GWh Rev.
0…9,999,999
•
•
•
Reverse gigawatt hours
7
30415-16
kWatth Rev.
0.000…999.999
•
•
•
Reverse kilowatt hours
8
30417-18
GWh Net
+/- 0…9,999,999
•
•
•
Net gigawatt hours
9
30419-20
kWatth Net
+/- 0.000…999,999
•
•
•
Net kilowatt hours
10
30421-22
GVARH Fwd
0…9,999,999
•
•
Forward gigaVAR hours
11
30423-24
kVARh Fwd
0.000…999,999
•
•
Forward kiloVAR hours
12
30425-26
GVARH Rev.
0…9,999,999
•
•
Reverse gigaVAR hours
13
30427-28
kVARh Rev.
0.000…999,999
•
•
Reverse kiloVAR hours
14
30429-30
GVARH Net
+/- 0…9,999,999
•
•
Net gigaVAR hours
15
30431-32
kVARh Net
+/- 0.000…999,999
•
•
Net kiloVAR hours
16
30433-34
GVAh Net
0…9,999,999
•
•
Net gigaVA hours
17
30435-36
kVAh 0.000…999,999
•
•
Net kiloVA hours
18
30437-38
Metering Iteration
0…9,999,999
•
•
•
Increments by 1 for each new
metering calculation.
Energy Results
Element
No.
Modbus
Address
Element Name
Range
TR1
TR2
EM1
EM2
EM3
Description
Demand Results Parameters
CSP File No.
F24
CIP Instance
17
No. of Elements
9
No. of Words
18
Data Type
Float
Data Access
Read
Demand Results
Element
No.
Modbus
Address
Element Name
Range
TR1
TR2
EM1
EM2
EM3
Description
0
30501-2
kWatt Demand
+/- 0.000…9,999,999
•
•
The average real power during the
last demand period.
1
30503-4
kVAR Demand
+/- 0.000…9,999,999
•
•
The average reactive power during
the last demand period.
2
30505-6
kVA Demand
0.000…9,999,999
•
•
The average apparent power during
the last demand period.
