78 Publication 1408-UM001B-EN-P - May 2008
Appendix A Powermonitor 1000 Data Tables
Energy Log Results Parameters
CSP File No. F26
CIP Instance 19
No. of Elements 21
No. of Words 42
Data Type Float
Data Access Read
Energy Log Results
Element
No. Modbus
Address Element Name Range
TR1 TR2 EM1 EM2 EM3
Description
0 30701-2 Internal Record
Identifier.
• • •
1 30703-4 Timestamp Year of
record -
• • •
The date and time when the
record was recorded.
2 30705-6 Timestamp
Month/Day -
• • •
3 30707-8 Timestamp
Hour/Minute -
• • •
4 30709-10 Timestamp
Seconds/
Hundredths
-
• • •
5 30711-12 Status 1 Count xM 0…9,999,999
• • •
Status 1 Count times
1,000,000
6 30713-14 Status 1 Count x1 0…999,999
• • •
Status 1 count times 1
7 30715-16 Status 2 Count xM 0…9,999,999
• • •
Status 2 Count times
1,000,000
8 30717-18 Status 2 Count x1 0…999,999
• • •
Status 2 count times 1
9 30719-20 GWh Net +/- 0…9,999,999
• • •
Net gigawatt hours
10 30721-22 kWatth Net +/- 0.000…999,999
• • •
Net kilowatt hours
11 30723-24 GVARH Net +/- 0…9,999,999
• •
Net gigaVAR hours
12 30725-26 kVARh Net +/- 0.000…999,999
• •
Net kiloVAR hours
13 30727-28 GVAh Net 0…9,999,999
• •
Net gigaVA hours
14 30729-30 kVAh Net 0.000…999,999
• •
Net kiloVA hours
15 30731-32 kWatt Demand +/- 0.000…9,999,999
• •
The average real power during
the last demand period.
16 30733-34 kVAR Demand +/- 0.000…9,999,999
• •
The average reactive power
during the last demand period.
